Trapezoidal Threaded Rod is used for various industrial equipments and they have a 30 degree flank angle. They hold a high pitch per turn of 3mm and outer diameter that ranges from 10 to 50mm. These are mostly used for lead screw and power screw. These are used for pivoting motions and they offer high strength and tremendous load bearing. Trapezoidal Lead Screw Nut has a thread form angle of 30 degree and this is cost effective product. This product is mostly used in applications like drive belts, hydraulic and pneumatic cylinders.
We are Manufacturer of wide range metric trapezoidal threaded rod, trapezoidal tap metric, 8mm trapezoidal threaded rod in China
DIN 103 trapezoidal Thread is thus used in many other applications like chemical industry, mechanical industry and many more. Apart from this, it is used in lead screw of lathe or spindle presses. Trapezoidal nut works by using roller screws which is in direct contact with screw thread.
for metric diameters Standard trapezoidal thread pitches
Nominal diameter (mm) |
Pitch (mm) |
|---|---|
10 |
2 |
12 |
3 |
14, 16 |
4 |
24, 28 |
5 |
32, 36 |
6 |
40, 44 |
7 |
48, 52 |
8 |
60 |
9 |
70, 80 |
10 |
90, 100 |
12 |
| Grade | S5346 |
|---|---|
| British standards | BS EN ISO 3506 |
| Length | 3 mm to 200 mm |
| Stainless Steel Threads: | UNC, UNF, METRIC, BSW, BSF or as required |
| SS Trapezoidal Threaded Rod Size | Stainless Steel Trapezoidal Threaded Rod (M45), M48, M2, M3, (M3.5), M4, M5, M6, M8, M10, M12, (M14), M16, (M18), M20, (M22), M24, (M27), M30, M33, M36, M42 to M160 and Custom Sizes |
| ISO – International Organization for Standardization | ISO 4017, ISO 4032, ISO 4033, ISO7380 JIS standards |
| UTS – Unified Thread Standard | UNS, NPT, NPTF, UNC, UNF, UNEF |
| DIN Standard | DIN 912, DIN 603, DIN 6923, DIN 970, B.S. DIN 933, DIN 931, DIN 934, DIN 913, DIN 7985, DIN 7981, DIN 7982, DIN916 |
| Type | Hex Head/ Truss head/Pan/ Round/ Oval |
| Tolerance | +/-0.01mm to +/-0.05mm |
| Dimensions | ASME B18.6.3 **Exception: screws 6 inches and shorter are fully threaded. |
| Head drive | Phillips/Slot, Phillips, Slotted, Six-Lobe, etc |
| application | Automotive industry, Construction, Electronic industry, Railway, Wind tower, Nuclear power |
| Head | Pan head, flat head, oval head, hex head, phillips head |
| Finishing |
|
Trapezoidal Tap suppliers in Shenzhen, China, Buy from Trapezoidal Screw manufacturers in China
Trapezoidal threaded bar has a 30 degree angle which differentiates from standard 29 degree. These are available in various sizes and accordingly those are manufactured. These are having its own weight chart and also it can be divided into six different thread types. This is really affordable and is used in smooth surface, highly durable and corrosion resistant. Metric acme lead screws and nuts are basically used as a translator rotary motion into linear motion.
Shop from Our Large Selection of metric acme lead screws and nuts in China, lead screw manufacturers
There are numerous Trapezoidal lead screw manufacturers in China. But the one which is highly acclaimed and ISO certified is High Temperature Fasteners Inc.. We are the excellent manufacturers who deliver the product on time and also the packaging is done properly so that the product is not damaged in the transporting process. Trapezoidal screw thread is codified by using DIN 103.
