SAE 1541 Round Bar

Grade SAE 1541 Round Bar is a medium carbon steel alloy. 1541 Hot Rolled Round Steel Bar also contains some content of manganese, in addition to residual elements like copper, nickel, molybdenum, and aluminium. Furthermore, both sulfur and phosphorous are also present in the 1541 Cold Rolled Steel Rod as impurities in the alloy.

view SAE 1541 Round Bar price, leading AISI 1541 Hot Rolled Round Steel Bar, Cold Rolled Steel Rod, Hot Rolled Steel Bar manufacturer



Check SAE 1541 equivalent grade, buy SAE 1541 material and carbon steel round bar at factory price

The SAE 1541 alloy steel Round Bars is a common alloy used for various applications because it is both versatile and affordable. The affordability of the aisi 1541 carbon steel round bar has been attributed to the lower alloying costs. Since the major alloying elements are only carbon and iron, the cost of a sae 1541 carbon steel round bar is much lower in comparison to an alloy such as stainless steel or nickel based alloys. As per specification, ASTM A29 can be supplied in or produced in the form of carbon 1541 Hot Rolled Steel Bar, cold-finished carbon steel bars, hot-rolled alloy steel bars, as well as cold-finished alloy steel bars.

A heat and product analysis are performed on the ASTM A29 1541 Round bar along with grain size test and some mechanical test. As specified in the ASTM A29 the Carbon Steel Grade 1541 round bar must conform to the grain size requirement. The sae 1541 mechanical properties, as well as the sae 1541 chemical composition, are required to conform to the  ASTM A29 specification.



---

EN15, EN15A, 37C15, 150M36, 36Mn7, SMn438



---

16mm, 18mm, 20mm, 22mm, 23.5mm, 24mm, 25mm, 26mm, 27mm, 28mm, 30mm, 32mm, 34mm, 35mm, 36mm, 37mm, 38mm, 40mm, 42mm, 45mm, 46.5mm, 47mm, 50mm, 51mm,53mm, 56mm, 60mm, 63mm, 65mm, 70mm, 75mm, 78mm, 80mm, 85mm, 90mm, 95mm, 100mm, 105mm, 110mm, 115mm, 120mm, 125mm, 130mm.

See SAE 1541 chemical composition and mechanical properties, Suppliers of AISI 1541 carbon steel round bar



---

Component	Weight %
C	Max 0.44
Fe	97.82 – 98.29
Mn	1.35-1.65
P	Max 0.040
S	Max 0.050



---

Mechanical Properties	Metric	English	Comments
Hardness, Brinell	>= 207	>= 207
Tensile Strength, Ultimate	>= 706.7 MPa	>= 102500 psi
Tensile Strength, Yield	>= 600 MPa	>= 87000 psi
Elongation at Break	>= 10 %	>= 10 %	in 2 in. (50 mm)
Reduction of Area	>= 30 %	>= 30 %
Modulus of Elasticity	200 GPa	29000 ksi	Typical Carbon Steel
Poissons Ratio	0.29	0.29	Typical Carbon Steel
Machinability	45.00%	45.00%	Cold Drawn AISI 1212 = 100%
Shear Modulus	78.0 GPa	11300 ksi	Typical Carbon Steel



Get 1541 Steel Round Bars, Carbon Steel Grade 1541 round bar, ASTM A29 1541 Round bar Stock

---

Thermal Properties	Metric	English	Comments
CTE, linear	12.0 µm/m-°C	6.67 µin/in-°F	Typical Carbon Steel
Specific Heat Capacity	0.470 J/g-°C	0.112 BTU/lb-°F	Typical Carbon Steel
Thermal Conductivity	52.0 W/m-K	361 BTU-in/hr-ft²-°F	Typical Carbon Steel



---

Physical Properties	Metric	English	Comments	Cold Head	Hot Forge	Wire Form
Density	7.85 g/cc	0.284 lb/in³



---

Electrical Properties	Metric	English	Comments	Cold Head	Hot Forge	Wire Form
Electrical Resistivity	0.0000170 ohm-cm	0.0000170 ohm-cm



Held wide stock of 1541 Bearing steel rod, SAE 1541 Bright Bars, SAE 1541 alloy steel Round Bars



---
