1141 Cold Drawn Bar

SAE 1141 Carbon Steel Round Bar manufacturer

ASTM A108/ A576 1141 Rod Supplier

1141 Cold Drawn Steel Bar

SAE 1141 Carbon Steel Round Bar

ASTM A108 1141 Rod

Like most carbon steels, the content of carbon in the alloy of grade 1141 is moderate. With moderate strength properties, the 1141 Steel Round Bar is referred to as a standard resulfurized steel. Generally, steels that have the number 11 in their grade are indicative of being resulfurized steel. Essentially the first number 1 informs the buyer that the 1141 Round Bar is of a carbon steel variety and the second number 1 means sulfur has been added to its alloy.

Being medium carbon steel, the alloy has some amounts of manganese as well. Resulfuriszed steel grades such as 1141 Steel Bar are often referred to as Free machining steel. The production of Free machining steel involves smaller chips while the alloy is machining. Using smaller chips is beneficial as it increases the machinability of the material used to produce grade 1141 Cold Drawn Steel Bar. To simplify, the use of smaller chips discourages entanglement in the machinery during the machining process, while also improving the rate at which the material gets machined.

The cost of producing Free machining steel grades like SAE 1141 Round Bars, is about 15% to 20% higher in comparison to conventional steels. Yet, the higher cost of producing these steel components has been offset by the added advantages like increased machining speeds, larger cuts of the 1141 Alloy Steel bar as well as longer tool life.

1141 Steel Round Bar Specification

Category	Steel
Class	Carbon steel
Type	Standard resulfurized
Designations	United States: ASTM A107 , ASTM A108 , ASTM A29 , ASTM A311 , FED QQ-S-637 , SAE J403 , SAE J412 , SAE J414 , UNS G11410

1141 Steel Round Bar Chemical Composition:

Carbon	.37
Manganese	1.35-1.65
Phosphorus (max)	.04
Sulfur (max)	.08-.13

1141 Steel Round Bar Mechanical Properties:

Tensile strength	97 ksi
Yield strength	52 ksi
Elongation in 2”	22%
Reduction of Area	38%
Brinell Hardness

Our Size Range Of 1141 Round Steel Bars:

16mm, 18mm, 20mm, 22mm, 23.5mm, 24mm, 25mm, 26mm, 27mm, 28mm, 30mm, 32mm, 34mm, 35mm, 36mm, 37mm, 38mm, 40mm, 42mm, 45mm, 46.5mm, 47mm, 50mm, 51mm,53mm, 56mm, 60mm, 63mm, 65mm, 70mm, 75mm, 78mm, 80mm, 85mm, 90mm, 95mm, 100mm, 105mm, 110mm, 115mm, 120mm, 125mm, 130mm.

Equivalent grades of SAE 1141 round bars:

1140, ASTM A108, ASTM A29, ASTM A311, ASTM A510, ASTM A576, SAE J1397, SAE J403, SAE J412, ASTM A107, FED QQ-S-637, SAE J414

Grades We Manufacture in addition to 1141 Round Bars:

MS, SAE 1018, IS 2062, A105, SAE 1008, SAE 1010, SAE 1141, C15, C18, C20, 1020, C22, 1022, C25, 1025, C30, 1030, C35, 1035, 35C8, S35C, C40, 1040, C45, 45C8, 1045, CK45, C50, 1050, C55, 55C8, 1055, C60, 1060, C70, 41Cr4, 40Cr4, 40Cr1, En18, En18D, SAE 1141, SAE 1536, 37Mn2, 37C15, En15, SAE 1141, LF2, EN19, SAE 4140, 42CrMo4, EN24, EN31, SAE 52100, 20MnCr5, 8620, EN1A, EN8, EN8D, EN9, ST 52.3, EN42, En353, SS 410, SS 202, SS 304, SS 316 and other grades as per customer requirement.
