#14 and 316 Stainless Steel Roofing Screws Suppliers at affordable price
Roofing Screws
316 Stainless Steel Roofing Screws
#14 SS Roofing Screws
view roofing screw sizes, oldest #10 Stainless Steel Roof Deck Screws, Hex Head Roofing Screws manufacturer
Usually, roofing screw manufacturers prefer producing roofing screws from either hardened carbon steel or stainless steel. These Stainless Steel Self Drilling Roof Screws coils are designed for used in conjunction with applications where the roofing materials are metal, plastic and fibreglass.
Different points of the Stainless Steel Metal Roofing Screws can be used for both metals as well as for wooden structures. To combat water penetration, all the Stainless Steel Hex Head Roofing Screws are required to have a sealing washer attached to them. This is one of the most obvious characteristics of the Type 17 Roofing Screws.
Essentially Stainless Steel Hex Head Roofing Screws are produced in two types of points. One of them is a drill point, whereas the other point of the Stainless Steel Roof Tile Screws is a sharp point. The 316 Stainless Steel Roofing Screws that have drill points will be used to fasten metal structures. On the other hand, the Stainless Steel Roof Deck Screws manufactured with sharp points are intended to be used in fastening wood structures. Most Stainless Steel Roofing Screws Suppliers recommend coating these screws in any of the following white, yellow, blue zinc coated or hot dipped galvanized or black oxidized coating in order to improve the corrosion resistance property of the alloy. Furthermore, different colours of paint could be painted on the heads of the #14 Stainless Steel Roofing Screws for specific applications.
|
SIZE
|
DRILL POINT
|
CASE QUANTITY
|
PART #
|
SIZE
|
DRILL POINT
|
CASE QUANTITY
|
|---|---|---|---|---|---|---|
|
1/4″ INDENTED HEX WASHER HEAD UNSLOTTED
|
||||||
|
#6 x 3/8″
|
#2
|
25,000
|
1500009
|
#8 x 3/4″
|
#3
|
14,000
|
|
#6 x 1/2″
|
#2
|
20,000
|
1500010
|
#8 x 1″
|
#3
|
10,000
|
|
#6 x 3/4″
|
#2
|
16,000
|
1500012
|
#8 x 1-1/4″
|
#3
|
7,000
|
|
#6 x 1″
|
#2
|
10,000
|
1500014
|
#8 x 1-1/2″
|
#3
|
5,000
|
|
#8 x 1/2″
|
#3
|
20,000
|
1500016
|
#8 x 2″
|
#3
|
4,000
|
|
#8 x 5/8″
|
#3
|
16,000
|
|
|
|
|
|
5/16″ INDENTED HEX WASHER HEAD UNSLOTTED
|
||||||
|
#10 x 1/2″
|
#3
|
10,000
|
1500029
|
#12 x 1-1/2″
|
#3
|
3,000
|
|
#10 x 5/8″
|
#3
|
10,000
|
1500030
|
#12 x 2″
|
#3
|
2,000
|
|
#10 x 3/4″
|
#3
|
10,000
|
1500031
|
#12 x 2-1/2″
|
#3
|
1,500
|
|
#10 x 1″
|
#3
|
8,000
|
1500032
|
#12 x 3″
|
#3
|
1,200
|
|
#10 x 1-1/4″
|
#3
|
6,000
|
1500033
|
#12 x 4″
|
#3
|
1,000
|
|
#10 x 1-1/2″
|
#3
|
4,000
|
1500039
|
14 x 7/8″
|
#3
|
3,000
|
|
#10 x 2″
|
#3
|
3,000
|
1500034
|
14 x 3-1/2″
|
#2
|
1,000
|
|
#10 x 2-1/2″
|
#3
|
2,000
|
1500035
|
14 x 4″
|
#3
|
500
|
|
#10 x 3″
|
#3
|
1,500
|
1500036
|
14 x 4-1/2″
|
#3
|
500
|
|
#12 x 3/4″
|
#3
|
8,000
|
1500037
|
14 x 5″
|
#3
|
500
|
|
#12 x 1″
|
#3
|
6,000
|
1500038
|
14 x 6″
|
#3
|
500
|
|
#12 x 1-1/4″
|
#3
|
4,000
|
|
|
|
|
|
3/8″ INDENTED HEX WASHER HEAD UNSLOTTED
|
||||||
|
#14 x 3/4″
|
#3
|
5,000
|
1500046
|
#14 x 3″
|
#3
|
1,000
|
|
#14 x 1″
|
#3
|
4,000
|
1500047
|
#14 x 3-1/2″
|
#3
|
1,000
|
|
#14 x 1-1/4″
|
#3
|
3,000
|
1500048
|
#14 x 4″
|
#3
|
1,000
|
|
#14 x 1-1/2″
|
#3
|
2,500
|
1500049
|
#14 x 4-1/2″
|
#3
|
1,000
|
|
#14 x 2″
|
#3
|
2,000
|
1500050
|
#14 x 5″
|
#3
|
500
|
|
#14 x 2-1/2″
|
#3
|
1,500
|
1500051
|
#14 x 6″
|
#3
|
500
|
|
SIZE
|
CASE QUANTITY
|
PART #
|
SIZE
|
CASE QUANTITY
|
|---|---|---|---|---|
|
#10 x 5/8″
|
10,000
|
1500021
|
#10 x 1″
|
6,000
|
|
#10 x 3/4″
|
10,000
|
1500023
|
#10 x 1-1/2″
|
4,000
|
|
#10 x 3/4″ SERR
|
10,000
|
1500025
|
#10 x 2
|
3,000
|
|
Size
|
Case Quantity
|
Part #
|
Size
|
Case Quantity
|
|---|---|---|---|---|
|
#12 x 1-5/8″
|
1,000
|
1206HHG
|
#12 x 4-1/2″
|
1,000
|
|
#12 x 2-1/4″
|
1,000
|
1207HHG
|
#12 x 5″
|
1,000
|
|
#12 x 2-7/8″
|
1,000
|
1208HHG
|
#12 x 6″
|
1000
|
|
#12 x 3-1/4″
|
1,000
|
1209HHG
|
#12 x 7″
|
500
|
|
#12 x 3-3/4″
|
1,000
|
1210HHG
|
#12 x 8″
|
500
|
|
SIZE
|
POINTS
|
CASE QUANTITY
|
LBS.
|
DRILL CAPACITY (IN.)
|
DRILL SPEED
|
MATERIAL APPLICATION
|
|---|---|---|---|---|---|---|
|
#12-24 x 7/8″
|
4
|
4,000
|
36
|
.125-.250
|
1500 RPM
|
Attaches Metal to Metal
|
|
SIZE
|
POINTS
|
CASE QUANTITY
|
LBS.
|
DRILL CAPACITY (IN.)
|
DRILL SPEED
|
MATERIAL APPLICATION
|
|---|---|---|---|---|---|---|
|
#14 x 7″
|
4
|
400
|
70
|
.125-.250
|
1500 RPM
|
Attaches Metal to Metal
|
|
#14 x 8″
|
4
|
300
|
80
|
.125-.250
|
1500 RPM
|
Attaches Metal to Metal
|
|
SIZE
|
POINT
|
CASE QUANTITY
|
LBS.
|
DRILL CAPACITY (IN.)
|
DRILL SPEED
|
MATERIAL APPLICATION
|
|---|---|---|---|---|---|---|
|
#12-24 x 1-1/4″
|
5
|
3,500
|
39
|
.125-.500
|
1500 RPM
|
Attaches Metal to Metal
|
|
#12-24 x 1-1/2″
|
5
|
2,500
|
33
|
.125-.500
|
1500 RPM
|
Attaches Metal to Metal
|
|
#12-24 x 2″
|
5
|
2,000
|
33
|
.125-.500
|
1500 RPM
|
Attaches Metal to Metal
|
|
#12-24 x 3″
|
5
|
1,000
|
23
|
.125-.500
|
1500 RPM
|
Attaches Metal to Metal
|
check roofing screw price, most trusted Stainless Steel Roof Tile Screws and roofing tek screws suppliers
- 1-1/2 in. Wood White Screw (250-Bag) : $36.10/bag
- 14 X 7/8 in. Ocean Blue Stitch Screw (250-Bag) : $38.80/bag
- 2 in. Wood Fastener (250 per Bag) : $67.96/bag
- 1-1/2 in. Galvalume Wood Screw (250-Bag) : $18.24
Please note this is an approx Cost of Class 5 Roofing Screws in China. For final Coloured Roofing Screws price list please mail us.
- Hex Head Roofing Screw
- Flange Head Roofing Screw
- Extra Long Roofing Screws
- Class 5 Roofing Screws
- #14 Stainless Steel Roofing Screws
- Stainless Steel Roof Deck Screws
- Collated Roofing Screw
- Stainless Steel Hex Head Roofing Screws
- 316 Stainless Steel Roofing Screws
- Stainless Steel Hex Head Roofing Screws
- Type 17 Roofing Screws
- Stainless Steel Roof Tile Screws
are you looking for Stainless Steel Metal Roofing Screws, Self Drilling Roof Screws suppliers
- Steel thickness from 22 ga (.028 in.) thru 18 gauge with min. 3/4 inch penetration.
- Wood 2x (1-1/2″ thick): Min penetration: 1″
- Plywood: Min thickness: 3/4″
- FR treated: min through penetration: 1/4″
- Stress Plates (generally stainless)
- Batten Bar, Stainless
- 410 Stainless Steel Roofing Screws, No. 14 Size
- Self-drilling point.
- Drill point design prevents fastener walking.
- Drill point cuts through gravel and BUR.
- 13 threads per inch for ease of installation.
- Head Type: #3 Phillips
- Head Height: Max .118″
- Head Dia: Max .440″
- Thread Major Dia: .235″
- Shank Dia: .180″
- Pull-out: (lbs avg.): Steel 24 ga: 325 Steel 22 ga: 470 Steel 20 ga: 635 Steel 18 ga: 815 3/4″ Plywood: 495
Types:
ASME B 18.6.4 & SAE J78 , #14 AF=9.5MM, #12 AF=8MM .POPULAR SIZE
- # 8X1/2″~2″
- #10 X 3/4″~3″
- #12X3/4″ ~ 4″
- #14X3/4″ ~ 6″
Din 7504k Style . 6.3mm Af=10mm , 5.5mm Af=8mm . Popular Size
8mm X 13mm ~ 75mm
5mm X 19mm ~ 100mm
3mm X 19mm ~150mm
Steel Bonded Washer 12mm & 14mm For 4.8mm(#10 ) Screw
Steel Bonded Washer 16mm & 19mm & 26mm For 5.5mm(#12) And 6.3mm(#14) Screw
Tek/drill Point No.2 ~ No.5 & Reduced #1 Available .
Make an inquiry to buy Type 17 Roofing Screws, Flange Head Roofing Screw, get a quote now
|
