Stainless Steel 310S Fasteners

SS 310S Hex Nuts and Bolts, UNS S31008 Studs suppliers in india

supplies a full range of DIN 1.4845 Threaded Rod at Factory price in China

Stainless Steel 310S Fasteners are made up of a low carbon version of the medium carbon stainless steel. The material has 25% chromium and 20% nickel in the chemical composition. High Temperature Fasteners Inc. is a leading manufacturer and supplier of the different types such as the SS 310S Hex Nuts And Bolts and others. The specifications for these fasteners are ASTM A193 and A194.

The length of the fasteners range from 3mm to 200mm and the sizes range from M3 to M56 or 3/6 inches to 2 inches with custom sizes available. The UNS S31008 Studs and other fasteners have 205MPa minimum yield strength and 515MPa minimum tensile strength. This is equivalent to the 18-8 austenitic stainless steel grades. The Brinell hardness of the fasteners is 217. The material has good thermal conductivity and electric resistivity. The types differ as nuts, bolts, washers, screws, threaded rods and other specified fasteners. The thread types of the DIN 1.4845 Threaded Rod and screw types vary according to the need of the applications.

The applications of this material made fasteners ranges from oil and gas to food processing industrial applications. The high temperature resistance and high wear resistance of the material makes the ASTM A479 Stainless Steel 310S Screws and other fasteners to be used in a variety of applications. Please feel free to contact us for more information and prices of the different types of fasteners in the 310 grade of stainless steel.







---

Fasteners Material Specification	ASTM A479, ASME SA479, UNS S31008 Bolts
Standard	DIN, UNI, ISO, JIS, GB, IS, BS, ASME, ANSI, ASTM and all International Standards
Fasteners/ Bolts Size	M2, M2.5, M3, M4, M5, M6, M8, M10, M12, M14, M16, M20, M24, M30, M36 to M160
Length	3 mm to 200 mm
Bolts, Studs Threads:	METRIC, BSW, BSF, UNC, UNF or as required
SS 310S Fasteners Standard:	ANSI – American National Standards Institute   ANSI B 18.2.4 2M ANSI B 28.2.4 1M SS 310S Stud Bolt length are defined in ASME B16.5 standard SS 310S Hex nuts are defined in ASME B18.2.2 ASME B18.5 DIN: DIN 931, DIN 933, DIN 934, DIN 970 UTS – Unified Thread Standard : UNC, UNF, UNEF, UNS, NPT, NPTF ISO – International Organization for Standardization : ISO 4032, ISO 4033, JIS standards
Source of raw materials	Tata Steel, JSPL, RINL, Usha Martin, Dhamm Steel, Mukund Steel etc.
SCOPE OF MANUFACTURE	Hot Forged Fasteners, Nut / Bolt; up to M36 / 1-1/2” Dia, up to 1100mm lg CNC Machined Fasteners, Nut / Bolt; up to M100 / 4” Dia, up to 1500mm lg
Fasteners In Form of:	Hex, Square, Round, Threading as per Gauge Etc.
Head drive:	Phillips, Slotted, Phillips/Slot, Six-Lobe, etc
bolting Test Certificate:	Manufacturer Test Certificate as per EN 10204 / 3.1
Fasteners finishing:	Zinc (yellow, white, blue, black), black oxide, Geometry, Dacroment, anodizing, nickel plated, plated zinc-nickel, Stainless steel: Passivated Self-Colour, Hot Dip Galvanised (HDG), Bright Zinc Plated (BZP), Sherardized, Stainless Steel, Mechanically Applied coating and some special one like DACROMET
Production process	M2-M24: Cold Froging, hot forging M24-M100, machining and CNC for Customized connecting element
bolting materials Surface Coating:	Teflon Coated Fasteners Phosphate Coated Fasteners Zinc Coated Fasteners Ptfe Coated Fasteners Xylon Coated Fasteners Cadmium Coated Fasteners Hot Dipped Galvanizing Coated Fasteners All surface finishes offered including Geomet & PTFE, Galvanised, Zinc, Electroless Nickel, Sherardized, Dacromet
Popular Types of SS 310S Bolts	Hex Bolts, Flange Bolts, Hex Head Bolts, Lag Bolts, Square Bolts, Eye Bolts, U Bolts, T Bolts, Counter sunk Bolts etc.
Popular Types of SS 310S Nut	Hex Head Nut, Eye Nut, Dome Nut, Wing Nut, T Nut, Panel Nut, Lock Nut, Coupling Nut, Square Nut, Acorn Nut etc.
Popular Types of SS 310S Screw	Hex Head Cap Screws, Socket Set Screws, Anchor Screws, Blind Rivet, Socket Head Screws, Concrete Screws, Shoulder Screws, Panel Screws, Threaded Screws, Machine Screws etc.
Popular Types of SS 310S Washer	Machine Washers, Flat Washer, Star Washers, Sealing Washer, Lock Washer, Split Washer etc.
Fasteners Packing:	IN BULK: canton, pallet, Small Boxs / carton / pallet, or customer request

---

Socket Head Cap Screw	$5.59–$258.50
Plow Bolt, Plain, 5/8-11×2, Gr 5, PK25	$30.65 / pkg. of 25
Structural Bolt, 1/2-13×1 1/2L, PKG25	$13.21 / pkg. of 25
U bolts, with 5/16 Thread, Zinc Finish	$3.71–$7.25
Hex Nut, SS, Gr SS310S,3/8-16, Plain, PKG50	$12.13
Hex Lag Screw, 3/8×2 1/2 In L, PKG50	$19.79
Flat Washer	$0.09–$5.97

Stainless Steel 310S Hex Nuts Pri ce in China (Thread Direction Right Hand)
Thread Size	310S stainless steel Hex Nuts Price	316 Stainless Steel Hex Nuts Price
#6-32	$45.11 / pkg. of 100	$33.68 / pkg. of 50
#6-32	$45.11 / pkg. of 100	$33.68 / pkg. of 50
#8-32	$45.22 / pkg. of 100	$36.05 / pkg. of 50
#10-24	$45.32 / pkg. of 100	$36.98 / pkg. of 50
7/16″-14	$19.42 / pkg. of 25	$22.04 / pkg. of 25
5/8″-11	$30.59 / pkg. of 25	$35.64 / pkg. of 25
3/4″-10	$35.23 / pkg. of 20	$41.51 / pkg. of 20
7/8″-9	$13.49 / pkg. of 5	$15.91 / pkg. of 5

M4-0.70mm , 8mm L, 10 PK	Price $20.14  / pkg. of 10
M4-0.70mm Cross Recessed Raised Cheesehead Screw, A2 Stainless Steel, 8mm L, 100 PK	Price $8.39  / pkg. of 100
M4-0.70mm , 60mm L, 50 PK	Price $24.31  / pkg. of 50
M4-0.70mm , 8mm L, 50 PK	Price $6.18  / pkg. of 50
M4-0.70mm , 50mm L, 100 PK	Price $20.45  / pkg. of 100
M4-0.70mm , 40mm L, 100 PK	Price $21.01  / pkg. of 100
M4-0.70mm , 45mm L, 100 PK	Price $18.23  / pkg. of 100
M4-0.70mm , 6mm L, 100 PK	Price $9.06  / pkg. of 100
M4-0.70mm , 50mm L, 100 PK	Price $25.60  / pkg. of 100
M4-0.70mm , 60mm L, 100 PK	Price $28.43  / pkg. of 100

M5-0.8 X 30	DIN 931	M5	Coarse	30	A2-70 Stainless	Plain	100	$11.20
M5-0.8 X 35	DIN 931	M5	Coarse	35	A2-70 Stainless	Plain	100	$13.43
M5-0.8 X 40	DIN 931	M5	Coarse	40	A2-70 Stainless	Plain	100	$15.03
M5-0.8 X 45	DIN 931	M5	Coarse	45	A2-70 Stainless	Plain	100	16.75
M5-0.8 X 50	DIN 931	M5	Coarse	50	A2-70 Stainless	Plain	100	$18.33
M6-1.0 X 10	DIN 931	M6	Coarse	10	A2-70 Stainless	Plain	100	$8.10
M6-1.0 X 30	DIN 931	M6	Coarse	30	A2-70 Stainless	Plain	100	$15.95
M6-1.0 X 35	DIN 931	M6	Coarse	35	A2-70 Stainless	Plain	100	$19.10

M4-0.70mm , 8mm L, 10 PK	Price $20.14  / pkg. of 10
M4-0.70mm Cross Recessed Raised Cheesehead Screw, A2 Stainless Steel, 8mm L, 100 PK	Price $8.39  / pkg. of 100
M4-0.70mm , 60mm L, 50 PK	Price $24.31  / pkg. of 50
M4-0.70mm Machine Screw, A4 Stainless Steel, 8mm L, 50 PK	Price $6.18  / pkg. of 50
M4-0.70mm Machine Screw, A4 Stainless Steel, 12mm L, 50 PK	Price $4.02  / pkg. of 50
M4-0.70mm , 50mm L, 100 PK	Price $20.45  / pkg. of 100
M4-0.70mm , 40mm L, 100 PK	Price $21.01  / pkg. of 100
M4-0.70mm , 45mm L, 100 PK	Price $18.23  / pkg. of 100
M4-0.70mm , 6mm L, 100 PK	Price $9.06  / pkg. of 100
M4-0.70mm , 50mm L, 100 PK	Price $25.60  / pkg. of 100
M4-0.70mm , 60mm L, 100 PK	Price $28.43  / pkg. of 100

Description	Price per 100	Pack
M1.4 X 2	$31.43	25
M1.4 X 3	$32.31	25
M1.4 X 4 SS 310S SOCKET CAP SCREW DIN 912 A2 ST/ST	$33.07	25
M1.4 X 5	$33.70	25
M1.4 X 6	$34.40	25
M1.4 X 8	$35.03	25
M1.4 X 10 SS 310S SOCKET CAP SCREW DIN 912 A2 ST/ST	$36.29	25
M1.4 X 12	$36.97	25
M1.4 X 16	$39.06	25
M1.6 X 3	$7.56	100
M1.6 X 4 SS 310S SOCKET CAP SCREW DIN 912 A2 ST/ST	$6.96	100
M1.6 X 5	$7.18	100
M1.6 X 6	$7.18	100
M1.6 X 8	$7.66	100
M1.6 X 10	$8.50	100
M1.6 X 12	$8.86	100
M1.6 X 14	$13.26	100
M1.6 X 16	$9.76	50
M1.6 X 18	$21.00	50

Please note this is an approx Cost of Stainless Steel 310S Fasteners in China. For final SS 310S Fasteners price list please mail us.



---



---

Stainless Steel 310S Bolt Type	SIZE	PROPERTY CLASS	TENSILE STRENGTH	STANDARD
Stainless Steel 310S Hex Head Bolt / Screws	M4 to M80	10.9	1040N / mm2 min	ISO 4017 (Full Thread) ISO 4014 (Half Thread)

Stainless Steel 310S Nuts Type	SIZE	PROPERTY CLASS	STANDARD
Hex Nut	M6 to M42	10	ISO 4032
Nylock Nut	M6 to M20 (Gr.8) M10 to M24 (Gr.10)	8 & `10	DIN 982
Nylock Nut	M6 to M20 (Gr.8) M10 to M24 (Gr.10)	8 & 10	DIN 985
Hex Weld Nut	M6 to M12	8	DIN 929

Stainless Steel 310S Washers Type	SIZE	HARDNESS	STANDARD
Square Section Spring Washer	3mm to 39mm	HV (430 to 530)	DIN 7980
Flat Section Spring Washer	3mm to 39mm	HV (430 to 530)	DIN 127 B
Hardened Washer	12mm to 30mm	HV (300 to 370)	IS 2016
Hardened Steel Washer	12mm to 56mm	Rockwell 26 to 45 (HDG) Rockwell 38 to 45 (Coated)	ASTM F436M

---

Metric	Closest Inch
M1.4-0.3	0-80 (Larger)
M2-0.4	1-64 (Smaller)
M2.5-0.45	3-56 (Larger)
M3-0.5	4-48 (Smaller)
M3.5-0.6	6-40 (Same)
M4-0.7	8-36 (Larger)
M5-0.8	10-32 (Smaller)
M6-1.0	1/4-28 (Larger)
M7-1.0	1/4-28 (Smaller)
M8-1.25	5/16-18 (Smaller)
M10-1.5	3/8-16 (Smaller)
M12-1.75	1/2-13 (Larger)
M14-2.0	9/16-12 (Larger)
M16-2.0	5/8-11 (Smaller)
M18-2.5	3/4-10 (Larger)
M20-2.5	3/4-10 (Smaller)
M22-2.5	7/8-9 (Larger)
M24-3.0	1-8 (Larger)
M30-3.5	1 1/8-7 (Smaller)
M36-4.0	1 3/8-6 (Smaller)

---

No.	Description
DIN 84	Slotted Cheese Head Machine Screws
DIN 85	Slotted Pan Head Machine Screws
DIN 94	Cotter Pin
DIN 125A	Flat Washer (without Chamfer)
DIN 125B	Flat Washer (with Chamfer)
DIN 127B	Split Lock Washer
DIN 137B	Spring Wave Washer
DIN 315	Wing Nut
DIN 439B	Machine Screws Hex Nut, Finished Hex Jam Nut
DIN 911	Long Arm Hex Key
DIN 912	Hex Socket Head Cap Screws
DIN 916	Hex Socket Set Screws
DIN 931	Hex Head Cap Screws Partially Threaded
DIN 933	Hex Head Cap Screws Fully Threaded
DIN 934	Finished Hex Nut
DIN 939	Double End Stud
DIN 960	Hex Head Cap Screws Partially Threaded
DIN 961	Hex Head Cap Screws Fully Threaded
DIN 963	Slotted Flat Head Machine Screws
DIN 964	Slotted Oval Head Machine Screws
DIN 965	Phillips Flat Head Machine Screws
DIN 966	Phillips Oval Head Machine Screws
DIN 975	Threaded Rod
DIN 980V	Hex Steel Prevailing Torque Lock Nut
DIN 985	Hex Nylon Insert Lock Nut
DIN 6334	Rod Coupling Nut
DIN 6797A	External Tooth Lock Washer
DIN 6797J	Internal Tooth Lock Washer
DIN 6912	Hex Low Socket Head Cap Screws
DIN 6921	Hex Flange Head Screws
DIN 6923	Hex Flange Nut
ISO 7379	Hex Socket Head Shoulder Screws
ISO 7380	Hex Button Socket Head Cap Screws
DIN 7985	Phillips Pan Head Machine Screws
DIN 7991	Hex Flat Socket Head Cap Screws

---



---

---

Grade	Density (kg/m3)	Elastic Modulus (GPa)	Mean Coefficient of Thermal Expansion (m/m/0C)			Thermal Conductivity (W/m.K)		Specific Heat 0-1000C (J/kg.K)	Electrical Resistivity (n.m)
			0-1000C	0-3150C	0-5380C	at 1000C	at 5000C
310S	7750	200	15.9	16.2	17.0	14.2	18.7	500	720

---

---
