316Ti Stainless Steel Round Bar and Rod

Trusted Astm A276 UNS S31635 Hex and Flat Bar Suppliers in China

See AISI 316Ti Square Bar available in 0.5m – 6m Lengths at our stockyard



Check dimension table of ASME SB 479 JIS 316Ti welding rod , Buy SUS 316Ti Bright Bar at factory price in China

Titanium on its own is an element that is known to exhibit superior properties. When used to alloy metals, they are able to achieve better characteristics, namely, the heat resistant behaviour and higher tensile strength of 316Ti Steel Cold Finished Bars. Referred to as marine grade, the alloy exhibits resistance to halide compounds, particularly those containing chlorine and bromine. Chlorine compounds are often a part of stream water sources, and vessels or components like JIS SUS 316Ti black bar which are used for marine engineering purposes benefit from their use.

Similar to grade 316l, the alloy for ss 316Ti bright bar is suited for applications involving welding operations. During welding, the carbon reacts with titanium, thus forming titanium carbides on the surface of the AISI 316Ti threaded bar instead of carbide precipitates. In comparison to carbide precipitates, titanium carbide is much stable. The DIN 1.4571 square bar is also resistant to sensitization at the grain boundary. Hence, the rate of intergranular corrosion in its alloy sees a decline. Another significant property of the ASTM A479 UNS S31635 hex bar is it’s superior resistance to oxidation.

Moreover, the rate of scaling in compared to other 316 alloys is much lower in the 316Ti stainless steel round bar.  Like most 316 variants, this stainless steel has better properties than grade 304, and hence the bar for corrosion resistance in the 316Ti stainless steel welding rod is much higher, with an increase in cost as well. Yet, compared to 316L, the addition of titanium in its alloy makes the astm a276 type 316Ti flat bar more expensive. Though the properties of titanium outweigh its expensive cost when used as an alloyant, it increases the overall cost of the alloy, making it on some occasions a difficult choice for the buyer. Hence, if properties like weldability, as well as elevated temperature use, is important, the buyer may choose to select 316Ti stainless steel rods.



---

• Standard : EN, DIN, JIS, ASTM, BS, ASME, AISI
• Specification : ASTM A276, A479 / ASME SA276, SA479
• Hex Bars : 18mm – 57mm (11/16″ to 2-3/4″)
• Square Bars : 18mm – 47mm (11/16″ to 1-3/4″)
• Round Bars : Outside Diameter in the range of 4mm to 500mm
• Bright Bars : Outside Diameter in the range of 4mm to 100mm
• Length : 1 to 6 Meters, Custom Cut Lengths
• Finish : Black, Bright Polished, Rough Turned, NO.4 Finish, Matt Finish, BA Finish
• Form : Round, Square, Hex (A/F), Rectangle Etc.



---

Material	Diameter	Length	Make
Stainless Steel Round Bar	0.5 mm to 500 mm	50 mm to 6000 mm Long	Chinan, European and Japanese origin



---

• Energy Industry
• Pharmaceuticals Industry
• Food Processing Industry
• Petrochemical Industry
• Pulp & Paper Indusry
• Chemical Industry
• Oil and Gas Industry
• Power Plant Industry
• Aerospace Industry

Find your choice of sizes from our DIN 1.4571 Bar Ready stock



---

Documentation



• Guarantee letter of the company
• Commercial invoice
• Chemical test report
• Mechanical test report
• Positive material test report
• Third party inspection statement
• Visual inspection statement

Material Testing

• Micro and macro test
• Chemical test
• Mechanical test
• Positive material identification test
• Third party inspections
• Visual inspections

Packing and Delivery

The product is wrapped and packed in wooden crates or carton boxes.



oldest Annealed and age hardened 316Ti Steel Cold Finished Bars exporter from China



---

	C	Ni	Mn	P	S	Si	Cr	Mo
MIN	0.040	10.000	–	–	–	–	16.000	2.000
MAX	0.100	14.000	2.000	0.040	0.030	1.000	18.000	3.000



---

	Yield Strength 0.2% Proof (MPa)	Tensile strength (MPa)	Elongation (% in 50mm)	Hardness (HRB)
MIN	170	485	40.00
MAX				95



---

Density	kg/dm³	8
Modulus of elasticity	GPa	200
Thermal conductivity	W/m°C	15
Heat capacity	J/kg°C	500
Electrical resistivity	µΩm	0.75
Poissons ratio		0.3



---



---

ASTM A276 SS 316Ti Round Bar UNS S31635 Round Bar AISI 316Ti Round Bar Stainless Steel 316Ti Round Bar SS 316Ti Round Bar SUS 316Ti Round Bars	ASTM A276 SS 316Ti Square Bar UNS S31635 Square Bar Stainless Steel 316Ti Square Bar SS 316Ti Square Bar SUS 316Ti Square Bars AISI 316Ti Square Bars	ASTM A276 SS 316Ti Hollow Bar SUS 316Ti Hollow Bars UNS S31635 Hollow Bars AISI 316Ti Hollow Bar Stainless Steel 316Ti Hollow Bar SS 316Ti Hollow Bar
UNS S31635 Hex Bar ASTM A276 SS 316Ti Hex Bar Stainless Steel 316Ti Hex Bar SS 316Ti Hexagonal Bar SUS 316Ti Hexagonal Bars AISI 316Ti Hex Bars	SUS 316Ti Bright Bars ASTM A276 SS 316Ti Bright Bar UNS S31635 Bright Bars Stainless Steel 316Ti Bright Bar SS 316Ti Bright Bar AISI 316Ti Bright Bar	SUS 316Ti Forged Bars ASTM A276 SS 316Ti Forged Bar UNS S31635 Forged Bar Stainless Steel 316Ti Forged Bar SS 316Ti Forged Bar AISI 316Ti Forged Bar
